8 VC7300 Series-Installation Guide
T
ERMINALS
, W
IRE
I
DENTIFICATION
& R
ATINGS
Part # VC3500E5000 VC3504E5000
VC3514E5000
Occupancy
Output
VC3400E5000 VC3404E5000
VC3300E5000
Slave Fan Unit
Low
Voltage
Terminals
No local inputs
Low voltage
inputs
Low voltage
inputs
No local inputs
Low voltage
inputs
No local inputs
1 1- Tx/Rx 1- Tx/Rx 1- Tx/Rx 1- Tx/Rx 1- Tx/Rx 1- Tx/Rx
2 2- 7 VDC 2- 7 VDC 2- 7 VDC 2- 7 VDC 2- 7 VDC 2- 7 VDC
3 3- Com 3- Com 3- Com 3- Com 3- Com 3- Com
4 4- RUI 1 4- RUI 1 4- RUI 1
5 5- Scom 5- Scom 5- Scom
6 6- RBI 2 6- RBI 2 6- RBI 2
7 7- SS 7- SS 7- SS
8 8- RS 8- RS 8- RS
9 9-Occ 9- Heat - 9- Heat -
10 10- Heat + 10- Heat +
LINE VOLTAGE CONNECTIONS
Power
Supply
Power supply: - 90 to 277 VAC universal all models
- Black Hot L1 Power VAC(Switches: Brown, Blue, Red, and Yellow)
- White neutral power VAC
Fan line
voltage
contact
Wire
connection
½ HP
Maximum
3 Fan Speed
Control Wires
Brown, Blue,
Red 3 Fan Speed
Control Wires
Brown, Blue,
Red 3 Fan Speed
Control Wires
Brown, Blue,
Red 3 Fan Speed
Control Wires
Brown, Blue,
Red 3 Fan Speed
Control Wires
Brown, Blue,
Red 3 Fan Speed
Control Wires
Brown, Blue,
Red
Valve line
voltage
contact
output
Yellow
wire
connection
10A
maximum
4 Pipes Cool
output
Or
2 Pipes Heat /
Cool output 4 Pipes Cool
output
Or
2 Pipes Heat /
Cool output 4 Pipes Cool
output
Or
2 Pipes Heat /
Cool output 2 Pipes Heat /
Cool output 2 Pipes Heat /
Cool output N/A
Valve line
voltage
isolated
contact
output
2 x Orange
wires
connection
10A
maximum
4 Pipes Heat
output
Or
2 Pipes reheat
output 4 Pipes Heat
output
Or
2 Pipes reheat
output 4 Pipes Heat
output
Or
2 Pipes reheat
output N/A N/A N/A
