7 VC7300 Series-Installation Guide
M
ODEL
C
HART
Part # VC3500E5000 VC3504E5000
VC3514E5000
Occ. Output
VC3400E5000 VC3404E5000
VC3300E5000
Slave Fan
Unit
Applications
2 pipes
2 pipes with
reheat
4 pipes
2 pipes
2 pipes with
reheat
4 pipes
2 pipes
2 pipes with
reheat
4 pipes
2 pipes
2 pipes with
modulating
pulsed reheat
2 pipes
2 pipes with
modulating
pulsed reheat
Slave fan
control only
Fan control Up to 3 speed Up to 3 speed Up to 3 speed Up to 3 speed Up to 3 speed Up to 3 speed
Monitoring
inputs
None
4 FCU remote
inputs
4 FCU remote
inputs
None
4 FCU remote
inputs
None
Control
types
On-Off line
switched valve
output control
- 1 heat / cool
output
- 1 cool output
- 3 fan outputs
On-Off line
switched valve
output control
- 1 heat / cool
output
- 1 cool output
- 3 fan outputs
On-Off line
switched valve
output control
- 1 heat / cool
output
- 1 cool output
- 3 fan outputs
- Occupancy
output
On-Off line
switched valve
output control
- 1 heat / cool
output
- 1 Modulating
pulsed Vdc
output for SSR
electric reheat
control
- 3 fan outputs
On-Off line
switched valve
output control
- 1 heat / cool
output
- 1 Modulating
pulsed Vdc
output for SSR
electric reheat
control
- 3 fan outputs
Slave fan
control only
3 fan outputs
Ordering Information Notes:
 Please refer to the “Operation overview” section for related information on VTR73xxA and
VC3xxxX arrangements and possible combinations.

More than one VC3xxxX Relay Pack can be used for a single VTR73xxA Terminal
Equipment Controller.
 Only one VC3x4X Relay Pack with monitoring inputs can be used for a single VTR73xxA
Terminal Equipment Controller
Ordering examples:
 A VC3500E5000 is for a 90 to 277 Vac powered FCU mounted Relay Pack with the
following outputs:

Three 90 to 277 Vac switching fan relay outputs

Two 90 to 277 Vac switching valve relay outputs
 A VC3504E5000 is for a 90 to 277 Vac powered FCU mounted Relay Pack with the
following inputs and outputs:
 One configurable universal input
 One configurable binary input

One dedicated discharge air temperature monitoring input

One dedicated return air temperature control input

Three 90 to 277 Vac switching fan relay outputs
 Two 90 to 277 Vac switching valve relay outputs
 A VC3300E5000 is for a 90 to 277 Vac powered FCU mounted Relay Pack with the
following outputs:

Three 90 to 277 Vac switching fan relay outputs
