13
SeqOpera Sequence of operation
Default is: Sequence #1 Single output application
(Out1Conf) = 2.0)
Dual output application
(Out1Conf) = 4.0)
0 = Cooling Only Yes access Yes access
1 = Heating only Yes access Yes access
2 = Cooling with Reheat Yes access Yes access
3 = Heating with Reheat Yes access Yes access
4 = Cool and Heat, 2 outputs No access Yes access
5 = Cool and Heat, 2 outputs with
Reheat No access Yes access
For single output applications, the system access is also limited if UI3 is configured for local changeover COS, COC/NC or COC/NC.
St-By TM
Stand-by Timer value
Default 0.5 hours
Time delay between the moment where the PIR cover detected the last movement in the area
and the time which the thermostat stand-by mode and setpoints become active.
Range is: 0.5 to 24.0 hours in 0.5hr increments
Unocc TM
Unoccupied Timer value
Default 0.0 hours
Time delay between the moment where the thermostat toggles to stand-by mode and the time
which the thermostat unoccupied mode and setpoints become active.
The factory value or 0.0 hours: Setting this parameter to its default value of 0.0 hours disables
the unoccupied timer. This prevents the thermostat to drift from stand-by mode to unoccupied
mode when PIR functions are used
Range is: 0.0 to 24.0 hours in 0.5hr increments
St-By HT
Stand-by heating setpoint
Default value = 69 °F
The value of this parameter should reside between the occupied and unoccupied heating
setpoints and make sure that the difference between the stand-by and occupied value can be
recovered in a timely fashion when movement is detected in the zone.
Stand-by heating setpoint range is: 40 to 90 °F ( 4.5 to 32.0 °C )
St-By CL
Stand-by cooling setpoint limit
Default value = 78 °F
The value of this parameter should reside between the occupied and unoccupied cooling
setpoints and make sure that the difference between the stand-by and occupied value can be
recovered in a timely fashion when movement is detected in the zone.
Stand-by cooling setpoint range is: 54 to 100 °F ( 12.0 to 37.5 °C )
Unocc HT
Unoccupied heating setpoint
Default value = 62 °F
Heating setpoint range is:
40 to 90 °F ( 4.5 to 32.0 °C )
Unocc CL
Unoccupied cooling setpoint limit
Default value = 80 °F
Cooling setpoint range is:
54 to 100 °F ( 12.0 to 37.5 °C )
heat max
Maximum heating setpoint limit
Default value = 90 °F ( 32 °C )
Maximum occupied & unoccupied heating setpoint adjustment. Heating setpoint range is:
40 to 90 °F ( 4.5 to 32.0 °C )
cool min
Minimum cooling setpoint limit
Default value = 54 °F ( 12 °C )
Minimum occupied & unoccupied cooling setpoint adjustment. Cooling setpoint range is:
54 to 100 °F ( 12.0 to 37.5 °C )
Set Type
Temporary setpoint enable
Default is : Permnent
Enables temporary setpoints
feature to any change of occupied
or unoccupied setpoint.
Temporar: (temporary) Local changes to the heating or cooling setpoints by the user are
temporary. They will remain effective for the duration specified by ToccTime. Setpoints will revert
back to their default value after internal timer ToccTime expires.
To change setpoints permanently, revert to No this variable or write setpoints through the
network. Any setpoints written through the network will be permanent ones and saved to
EEPROM.
Permnent: (permanent) Any change of occupied or unoccupied setpoints through the keypad by
the user are permanent and saved to & EEPROM
TOccTime
Temporary occupancy time
Default value = 2 hours
Temporary occupancy time with occupied mode setpoints when override function is enabled
When the thermostat is in unoccupied mode, function is enabled with either the menu or BI1 or
BI2 configured as remote override input. 0,1, 2, 3, 4, 5, 6, 7, 8, 9, 10, & up to 24 hours
deadband
Minimum deadband
Default value = 2.0 °F ( 1.0 °C )
Minimum deadband value between the heating and cooling setpoints. If modified, it will be
applied only when any of the setpoints are modified.
2, 3, 4 or 5 °F, 1.0 °F increments ( 1.0 to 2.5 °C, 0.5 °C increments )
cal RS
Room air temperature sensor
calibration
Default value = 0.0 °F or °C
Offset that can be added/subtracted to actual displayed room temperature
± 5.0 °F, 1.0 °F increments ( ± 2.5 °C, 0.5 °C increments )
