9 | VT7682S Series-Installation Guide
When left unattended for 45 seconds, the display will resume automatic status display
scrolling.
To turn on the back light, press any key on the front panel. The back lit display will turn off
when the Terminal Equipment Controller is left unattended for 45 seconds
Sequence of user menu:
OVERRIDE
RESUME
TEMPERATURE
SETPOINTS
SYSTEM
MODE
SETTING
SCHEDULES
SETTING
CLOCK
SETTING
Override
schd Y/N
Temperat
Set Y/N
Sys mode
set Y/N
Schedule
set Y/N
Clock
set Y/N
Appears only in
unoccupied mode
Cancel
ovrd Y/N
Appears only in
override mode
Occupied setpoints adjustments
There is a default profile set in the Terminal Equipment Controller from the factory.
DEFAULT TEMPERATURE SETPOINTS: DEFAULT MODES:
Occupied cooling setpoint = 24 °C (75 °F) System mode = Auto
Occupied heating setpoint = 22 °C (72 °F) Monday through Sunday
Fahrenheit scale Occupied time is : 12:00 AM
Unoccupied time is: 11:59 PM
There will be a 1 minute unoccupied period every night at 11:59 PM with this default configuration.
A) Override an unoccupied period
Override
schd Y/N
This menu will appear only when the Terminal Equipment Controller is in unoccupied
mode. Answering yes to this prompt will cause the Terminal Equipment Controller to go
into occupied mode for an amount of time equal to the parameter “TOccTime” (1 to 12
hours).
B) Resume regular scheduling
Cancel
ovrd Y/N
This menu does not appear in regular operation. It will appear only when the Terminal
Equipment Controller is in Unoccupied override mode.
Answering “Yes” to this question will cause the Terminal Equipment Controller to resume
the regular setpoints & scheduling.
