10 | VT7682S Series-Installation Guide
C) Temperature setpoints
Temperat
set Y/N
This menu permits the adjustment of occupied temperature setpoints as well as the
desired temperature units (°F or °C). Setpoints are written to RAM and EEPROM.
Cooling setpoint
Occupied mode
Heating setpoint
Occupied mode
°F or °C
display setting
Cooling
set? Y/N No next

Yes down

Heating
set? Y/N No next

Yes down

°F or °C
set? Y/N No next

Yes down

Use ▲▼ keys to set value, Yes key to confirm
Cooling
70.0 °F
Use ▲▼
To set value
Heating
68.00 °F
Use ▲▼
To set value
Units
°F
Use ▲▼
To set value
D) System mode setting
Sys mode
set Y/N
This menu is accessed to set system mode operation
Use ▲▼ to set value, Yes key to confirm
Sys mode
auto
Automatic mode
Automatic changeover mode between heating and cooling operation
Sys mode
cooling
Cooling mode
Cooling operation mode only
Sys mode
heating
Heating mode
Heating operation mode only
Sys mode
off
Off mode Normal cooling or heating operation disabled
If enabled in installer parameters, only the automatic heating frost protection
at 50 °F ( 10 °C ) is enabled
E) Schedule set (2 events)
Scheduling can have 2 or 4 events per day. This is set in the configuration menu as per
parameter (2/4event)
Schedule
set Y/N
This section of the menu permits the user to set the whether 2 or 4 events is needed.
Each day can be tailored to specific schedules if needed.

2 events can be scheduled per day.

Occupied & unoccupied periods can be set for each day.
MONDAY TIMER
SCHEDULE SET
TUESDAY
TIMER
SCHEDULE SET
WEDNESDAY
TIMER
SCHEDULE SET
OTHER DAYS ARE
IDENTICAL
Monday
set? Y/N
No next

Yes down

Tuesday
set? Y/N
No next

Yes down

Wednesda
set? Y/N
No next

Yes down

Selects the day to be scheduled or
modified
Yes key to access day scheduling, No key to jump to next day
