15 | VT7682S Series-Installation Guide
CONFIGURATION
PARAMETERS
DEFAULT VALUE
SIGNIFICANCE AND ADJUSTMENTS
PswrdSet
Configuration parameters
menu access password
Default value = 0
No password prompted This parameter sets a password access to prevent
unauthorized access to the configuration menu
parameters. A default value of “0” will not prompt a
password or lock the access to the configuration
menu.
Range is: 0 to 1000
Com Addr
Terminal Equipment
Terminal Equipment Controller
networking address
Default value = 254
This parameter is used to set the MAC address.
Range is: 0 to 254
PAN ID
Personal Area Network
Identification
Default value = 0
This parameter (Personal Area Network
Identification) is used to link specific Terminal
Equipment Controllers to a single specific Viconics
VT7682S Wireless Central Manager. A maximum of
120 Terminal Equipment Controller can be linked to a
single VT7682S Wireless Central Manager. Be sure
you set the SAME PAN ID value both at the Wireless
Central Manager and the Terminal Equipment
Controller(s).
The default value of 0 is NOT a valid PAN ID.
Range is: 0 to 500
Channel
Channel selection
Default value = 10
Range is: 10 to 25
This parameter (Channel) is used to link specific
thermostats to specific Terminal Equipment
Controllers to a single specific Viconics VT7682S
Wireless Central Manager. A maximum of 120
Terminal Equipment Controller can be linked to a
single VT7682S Wireless Central Manager. Be sure
you set the SAME PAN ID value both at the Wireless
Central Manager and the Terminal Equipment
Controller(s).
Viconics recommends using only the 2 last channels
( 24-@ 2470MHz and 25-@ 2475MHz )
The default value of 10 is NOT a valid channel. The
valid range of available channel is from 11 to 25
