Specifications
Terminal Equipment Controller power
requirements:
Operating conditions:
Storage conditions:
Outdoor air Temperature sensor
Wire gauge:
Approximate shipping weight:
Agency Approvals all models:
Agency Approvals all models:
Agency Approvals Wireless models:
19-30 VAC 50 or 60 Hz; 2 VA Class 2
0 °C to 50 °C ( 32 °F to 122 °F )
0% to 95% R.H. non-condensing
-30 °C to 50 °C ( -22 °F to 122 °F )
0% to 95% R.H. non-condensing
-40 °C to 50 °C ( -40 °F to 122 °F )
18 gauge maximum, 22 gauge
0.75 lb ( 0.34 kg )
UL: UL 873 (US) and CSA C22.2 No.
24 (Canada), File E27734 with CCN
XAPX (US) and XAPX7 (Canada)
Industry Canada: ICES-003 (Canada)
FCC: Compliant to CFR 47, Part 15,
Subpart B, Class A (US)
CE : EMC Directive 89/336/EEC
(Europe Union)
C-Tick: AS/NZS CISPR 22 Compliant
(Australia / New Zealand) Supplier
Code Number N10696
FCC: Compliant to: Part 15, Subpart C
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS
DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
 When replacing an existing Terminal Equipment Controller, label the wires
before removal of the Terminal Equipment Controller.
 Electronic controls are static sensitive devices. Discharge yourself properly
before manipulating and installing the Terminal Equipment Controller.
 A short circuit or improper wiring may permanently damage the Terminal
Equipment Controller or the equipment.
 All VT7000 series Terminal Equipment Controllers are designed for use as
operating controls only and are not safety devices. These instruments have
undergone rigorous tests and verification prior to shipping to ensure proper and
reliable operation in the field. Whenever a control failure could lead to personal
injury and or loss of property, it becomes the responsibility of the user or
installer or electrical system designer to incorporate safety devices (such as
relays, flow switch, therma
l protections, etc…) and or an alarm system to
protect the entire system against such catastrophic failures. Tampering with the
devices or unintended application of the devices will result in a void of
warranty.
