Status LED Indicators
Tips & Things You Need to Know
1.14. Compatibility
The Wireless Central Manager is compatible with all VT7xxxX and VTR73xxA wireless controllers and can
be mixed and matched with different models in a single system.
1.15. Maximum Devices
A single Wireless Central Manager can administer up to 60 controller units. If more than 60 controller
units are required, a second Wireless Central Manager will be needed.
Wireless Central Manager Adapter LED Status Indicators
1 x(200ms) short
blink Power on.
2 x (200ms) short
blinks Power on and communicating with Wireless Central Manager.
3 x (200ms) short
blinks Power on, communicating with Wireless Central Manager and wireless network initializing.
4 x (200ms) short
blinks Power on, communicating with Wireless Central Manager and wireless network started successfully.
4 x (200ms) short
blinks
And
1 x (1500ms) long
blink Power on, communicating with Wireless Central Manager and wireless network started successfully
and wireless communication with wireless controllers are active.
System Troubleshooting Recommendations
1. If a controller is not detected by a Wireless Central Manager, verify that the LED is blinking at least 4 times. If it is only blinking twice, ensure
that the PAN and Channel of the controller is the same as the Wireless Central Manager it must communicate with.
2. When commissioning a network, it is recommended to use channels 15 or 25. Alternate these channels between floors.
3. If a particular controller refuses to join the network and cannot be seen by the Wireless Central Manager. Please move momentarily closer to
the Wireless Central Manager until it has joined the network and it is added to the database. It can then be re-located to its original position.
Wireless
Central
Manager
All VT7600 Series
models
VT7200 / 7300
Series models
All VTR7300 Series
models
