10
Parameter Variable Name Function
This output network variable is used to indicate the actual
occupancy mode of the unit. This information is typically reported
to a supervisory controller or provided to another Space Comfort
Controller to coordinate the operation of multiple units
Valid Range:
0 = OC_OCCUPIED
1 = OC_UNOCCUPIED
2 = OC_BYPASS
1
Occupancy network output
SNVT_occupancy
nvoEffectOccup
3 = OC_STANDBY – Not Used
NOTE : OC_BYPASS can be initiated by either nviOccManCmd or a
local input. NvoEffectOccup will only be in OC_BYPASS for the
duration of the ToccTime (nciGenOpts), until reinitiated by either a
transition of the local input or an update to nviOccManCmd.
This network variable output is used to report the Space Comfort
Controller inputs’ and outputs’ status.
Name Valid value True Bit Index
fan output 0 = Off
1 = On 2
cooling stage 1 0 = Off
1 = On 3
cooling stage 2 0 = Off
1 = On 4
auxiliary contact 0 = Off
1 = On 5
heating stage 1 0 = Off
1 = On 6
heating stage 2 0 = Off
1 = On 7
di1 direct status 0 = Activated
1 = Not Activated 17
local pir motion 0 = No motion
1 = Motion 24
service alarm 0 = Off
1 = On 12
filter alarm 0 = Off
1 = On 13
fan lock alarm 0 = Off
1 = On 25
set clock alarm 0 = Off
1 = On 22
Thermostat’s
I/O status network output
UNVT_thermo_state
_rh
nvoSccStatus
frost protection alarm 0 = Off
1 = On 23
