Product Overview


The VT76xx PI controller family is specifically designed for single stage and
multi-stage control of heating/cooling equipment such as rooftop and self-
contained units. The product features an intuitive, menu-driven, back-lit LCD
display, which walks users through the programming steps, making the process
extremely simple. Accurate temperature control is achieved due to the product’s
PI time proportional control algorithm, which virtually eliminates temperature
offset, associated with traditional, differential-based controllers.

The controllers are also compatible with the new Viconics PIR cover accessories.
Controllers equipped with a PIR cover provide advanced active occupancy logic,
which will automatically switch occupancy levels from Occupied to Unoccupied as required by local activity being
present or not. This advanced occupancy functionality provides advantageous energy savings during occupied
hours without sacrificing occupant comfort. All controllers can be ordered with or without a factory installed PIR
cover.

Fig.1 - VT7600 Series

The additional following documentation is available on

www.viconics.com

- Detailed information on the controller (VT76xxX5x00x), is available on document: LIT-VT7600-PIR-E00.doc
- Detailed information on the controller (VT76x7X5x00x), is available on document: LIT-VT76x7-PIR-E00.doc
- PIR application information and examples, are available on document: APP-VT76-PIR-Guide-Exx
- PIR cover installation information is available on document: PIR Cover Installation-Exx


Contents

Subject

VT76xx series Protocol Implementation Conformance Statements (PICS)

Objects Table

Standard Object Types Supported

List of Proprietary Properties

List of Property Value Range

List of Property Enumeration Set for BI's and BV's

List of Property Enumeration Set for MV's

Integration - Global commands

Integration - Graphic User Interface (GUI) Objects

Integration - Configuration Objects

Wiring Guide

Overview

Network Configuration

Maximum Number of Devices

Maximum Cable Length

EI-485 Repeaters

End Of Line Resistors

Network Adapter

Default Device Name and Device ID

Integrating Viconics’ Devices on an MSTP Network

Tips and Things You Need To Know

Troubleshooting Section

Document Control
