USL XTM-300 User Manual
Page 23
23
In the speaker library window, use the dropdown menu to select a particular speaker from the
speaker library.
You may load channels by checking the boxes in the library window. When you have selected
the channels you want, click “OK” to close the “Speaker Library” window. At this time, the set-
tings you selected are loaded into the XTD-680 and will be reflected in the display and the
data at the bottom of the display. You may un-mute the system and audio should be present.
This would be a good time to do a Disconnect and select “Save”. After doing a Disconnect/
Save, the XTM-300 should be power cycled. When the unit comes back on, it should be ready
for use with the speaker crossover settings you saved.
Bypass Crossover DIP Switch Setting
.
Bypass Crossover
1 2 3 4 5 6
BIAMP 300 Hz
OFF
ON
OFF
ON
OFF ON
BIAMP 1khz
OFF
OFF
ON
OFF
ON
ON
Dipswitch Setting
