USL XTM-300 User Manual
Page 13
13
Pin Function
Pin Function
1 Earth
14
Ll-
2 Ll+
15
Earth
3 Lrs-
16
Lrs+
4 Earth
17
Cl-
5 Cl+
18
Earth
6 Rrs-
19
Rrs+
7 Earth
20
Rl-
8 Rl+
21
NC
9 Earth
22
Earth
10 Ls-
23 Ls+
11 Rs-
24 Rs+
12 LFE-
25 LFE+
13
Earth
Output Lows & Surrounds
DB25 Male
Pin Function
Pin Function
1 Earth
14
Lh-
2 Lh+
15
Earth
3 NC
16
NC
4 Earth
17
Ch-
5 Ch+
18
Earth
6 NC
19
NC
7 Earth
20
Rh-
8 Rh+
21
NC
9 Earth
22
Earth
10 NC
23 NC
11 NC
24 NC
12 Spare-
25 Spare+
13
Earth
Output Highs DB25 Male
