USL XTM-300 User Manual
Page 14
14
Pin Lows
Highs
Surrounds
1 Ll+
Lh+
Ls+
2 Ll-
Lh-
Ls-
3 Earth
Earth
Earth
4 Cl+
Ch+
Rs+
5 Cl-
Ch-
Rs-
6 Rl+
Rh+
Lrs+
7 Rl-
Rh-
Lrs-
8 Earth
Earth
Earth
9 LFE+
Spare
Input+*
Rrs+
10 LFE-
Spare
Input-*
Rrs-
Phoenix Outputs (Parallel the DB25s)
* Note: The spare input connects directly to the high band DB25 output to drive the CM-8E
