CCH-100 Manual
Page 2
Introduction
The CCH-100 is a pair of closed caption glasses, called CaptionWear™, used in movie
auditoriums. It receives captions for up to four languages from the USL IRC-28C IR
panel and displays the captions.
Operation
Put the lanyard around your neck, Captionwear™ on your head and slide the power
supply switch on towards the LED. The green LED will light. Sample captions will dis-
play. When you’re in the auditorium, a welcome message will be displayed until the
movie starts. When captioned content plays, the captions will appear.
Note: Not all previews or movies are captioned.
Push the red language button to select a different language or adjust captions that
appear upside-down.
Note: The default language is English so it will not be necessary to push the Language
Button unless you prefer another language.
You may adjust the Up/ Down Adjustment Knobs on the side of the CaptionWear™ to
move the text up and down. If the text is cut off on the left or right side, use the Ad-
justable Nose Pad Lever to center the text. The Image Focus Ring may be rotated to
improve the text focus.
When the movie is over, slide power supply switch to the off position. The green LED
will turn off. Return the unit.
Language Button
Power Supply On / Off Switch
Lanyard
Up / Down Adjustment Knob
Adjustable Nose Pad Lever
Up / Down Adjustment Knob
Image Focus Ring
