Operations Guide – DOC. 6144 2-Way RF Wireless Touchpanel: STX-1700CXP • 5
Physical Views (continued)
The underside of the unit contains the battery compartment that holds one ST-BTPN.
Contacts for the ST-DSN are through the ST-BTPN. Four rubber feet on the
underside of the unit are for stability and to prevent slippage on flat surfaces.
Refer to “Programming Cable” on page 22 for details and pinouts of the cable used
for programming and uploading.
