Page 36: Antenna building top of gateway
2-Way RF Wireless Touchpanel
Crestron STX-1700CXP
32
• 2-Way RF Wireless Touchpanel: STX-1700CXP
Operations Guide - DOC. 6144
Horizontal Orientation
Top of gateway
Antenna
Building
Vertical Orientation
TPS-RFGWX
Antenna
Front of
gateway
Building
RF GATEWAY - 2 WAY
P WR
NET
Rx
SIG
R F
Tx
ANTENNA
CRESTRON
Right Angle Orientation
Antenna
Building
Top of gateway
