INTRODUCTION
Top Flite is very proud to bring you the giant scale Zero.
The Zero became one of the most important fi ghters of
World War II. You will enjoy using this scale accessory
to add to the overall look and enjoyment of your Zero.
KIT CONTENTS
REQUIRED FOR COMPLETION
❍ 1- Futaba S3102 Servo 50 oz. in. of torque
(FUTM0034)
❍ ½ oz. Medium Pro CA+ (GPMR6009)
ORDERING REPLACEMENT PARTS
Replacement parts for the Top Flite Giant Scale Zero
ARF are available using the order numbers in the
Replacement Parts List that follows. The fastest, most
economical service can be provided by your hobby
dealer or mail-order company.
To locate a hobby dealer, visit the Top Flite web
site at www.top-flite.com. Select “Where to Buy” in
the menu across the top of the page and follow the
instructions provided to locate a U.S., Canadian or
International dealer.
Parts may also be ordered directly from Hobby Services
by calling (217) 398-0007, or via facsimile at (217) 398-
7721, but full retail prices and shipping and handling
charges will apply. Illinois and Nevada residents will
also be charged sales tax. If ordering via fax, include
a Visa
® or MasterCard ® number and expiration date
for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
Be certain to specify the order number exactly as listed
in the Replacement Parts List. Payment by credit card
or personal check only; no C.O.D.
If additional assistance is required for any reason
contact Product Support:
by e-mail at or by telephone at
productsupport@top-fl ite.com (217) 398-8970
REPLACEMENT PARTS LIST
TOPA1956 . . Giant Zero Drop Tank
Complete Parts Set
TOPA1949 . . Giant Zero Drop Tank Release Set
TOPA1948 . . Giant Zero Drop Tank Set
ASSEMBLE THE
DROP TANK MOUNT
❏
1. Locate the ABS drop tank mount. Cut it as shown.
❏
2. Locate the plywood former, plywood mounting
screw doublers and 1/4-20

2" [ 51mm] nylon mounting
screws. Insert the screws into the doublers.
❏
3. IMPORTANT! When assembling the parts that
follow, pay close attention to the photos. Make sure you
assemble the parts exactly as shown. Place one of the
doublers and screws in place on the former. Center
