5
Remove
Insert
Camera mounting screw
(accessory) (Quantity: 4)
Waterproof washer
(accessory) (Quantity: 4)
C-CC704's case
Sealing areas
4. INSTALLATION
1. Run the composite cable supplied with the C-CC704 through the cable bushing supplied with the unit.
Remove the connectors on the end of the composite cable before running the cable through the cable
bushing.
2. Secure the Pendant adapter to the C-CC704's case.
3. Secure the cable bushing into the upper side of the pendant adapter while running the free end of
composite cable through the C-CC704's case from the upper pendant adapter.
Waterproof the cable bushing mounting area and the cable outlet end with silicone sealant material.
