C-CH100 Series Outdoor Camera Housing
[Bottom view] C-BC200 Series Outdoor Camera Housing
[Bottom view]
C-BC200H Housing Fixing Stand
Housing Fixing Stand mounting bolt (accessory)
(M6 x 12 hexagonal head bolt with washer): 2 pieces
Camera housing mounting bolt*
[C-CH200 Series]
M6 x 12 hexagonal head bolt
with washer: 2 pieces
[C-CH100 Series]
M6 x 12 hexagonal head bolt: 2 pieces
M6 spring washer: 2 pieces
M6 plain washer: 2 pieces
C-BC200K Wall Mounting Bracket
INSTALLATION
Ensure that each bolt is securely tightened after mounting the camera
housing and wall mounting bracket to a wall. If there is any loose
joint, the unit may fall, possibly resulting in personal injury.
WARNING
* Supplied with the C-CH100 or C-CH200 Series Outdoor Camera Housings.
