TS-773 TS-774
Electret condenser microphone
Unidirectional
1.8 kΩ
–37 dB (1 kHz, 0 dB = 1 v/Pa)
Speech Indicator (ring type)
100 – 13,000 Hz
Equivalent to XLR-4-32
Gooseneck: Stainless steel, black
Other:
ABS resin, black
368 mm (14.49") 518 mm (20.39")
90 g (3.17 oz) 105 g (3.7 oz)
TS-771 Chairman unit, TS-772 Delegate unit
Model No.
Type
Directivity
Rated Impedance
Rated Sensitivity
LED Indicator
Frequency Response
Output Connector
Finish
Length
Weight
Applicable Unit (Option)
133-02-00102-00
URL: http://www.toa.jp/
14.3. TS-773 and TS-774 Microphones
Note: The design and specifications are subject to change without notice for improvement.
14.4. TS-775 Remote Delegate Interface Unit
Power Source 35 V DC, under 30 mA (supplied from TS-770 Central unit)
Input –50 dB*, 200 Ω, balanced, mini jack, equipped with a volume control
Output –40 dB*, 22 Ω, balanced, mini jack, equipped with a volume control
Speech Mode Auto: Voice-activated Automatic switching
Manual: Talk key on-off switching
Operating Temperature 0°C to 40°C (32°F to 104°F)
Operating Humidity Under 90 % RH (no condensation)
Finish Pre-coated steel plate, black
Dimensions 160 (w) x 41.8 (h) x 100 (d) mm (6.3" x 1.65" x 3.94") (excluding projection)
Weight 700 g (1.54 lb)
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
YR-770-2M YR-770-10M
DIN socket (8P, unit's rear-mounted connector side),
DIN plug (8P, unit's cord connector side)
2 m (78.74") 10 m (393.7")
Model No.
Connector
Length
14.5. YR-770-2M 2 m Extension Cord and YR-770-10M 10 m Extension Cord
Note: The design and specifications are subject to change without notice for improvement.
