Manufactured Housing Products Division

TIE DOWN ENGINEERING

255 Villanova Drive S.W. • Atlanta Georgia 30336

(800) 241-1806 • (404) 344-0000 • Fax (404) 349-0401

Trade, Brand, and Product Names are the Property of

TIE DOWN ENGINEERING, ©2012 TIEDOWN, Inc.

Minimum Number of Lag Screws Required

Roof Live Load / Flat Roof Snow Load (PSF)

Strut

Spacing

4’ - 0”

5

6

6

7

7

8

8

9

9

20

25

30

35

40

45

50

55

60

5’ - 4”

7

8

8

9

9

10

11

11

12

6’ - 8”

8

9

10

11

12

13

13

14

15

8’ - 0”

10

11

12

13

14

15

N/A

N/A

N/A

Heavy Duty System

Part #59373

Page 4
