Tie Down Base - Magma Table Dua Mounting - Manual (Page 2)

TIE DOWN ENGINEERING • 255 Villanova Drive SW • Atlanta, GA 30336
www.tiedown.com (404) 344-0000 Fax (404) 349-0401 021813,A1312
Mounting Base
for Magma Table Mount
GalvX #86915 / Galvanized #86933
Eye bolts secure the receiver
to the base. Once the holes are aliened
hand tighten all eye bolts.
1
2
1
3
Installation Instructions:
1. Slide base of accessory tube into receiver until threaded holes align with holes in receiver.
2. Slide eye bolts through receiver side holes and screw into threaded holes in accessory base. Hand tighten all
eye bolts and then use screw driver shaft to tighten one half turn.
3. Carefully lift the mounted table/base. Position the base mount (2) above the support tube (1) and slide the
base mount into the support tube (1).
4. Using 2 - knobs (3) secure grill base (2) to accessory base (1)
46.87
11.72
19.50
