Dock Box Mounts
GalvX #86907 / Galvanized #86925
Eye bolts secure the receiver
to the rack base. Once the holes are aliened
hand tighten all eye bolts.
1
1
Assembly Instructions:
1. Read and follow mounting instructions that
accompany your dock box. Each Dock Box Mount
has (1/4”) pre drilled mounting holes.
Installation Instructions:
1. Slide base of accessory tube into receiver until
threaded holes align with holes in receiver.
2. Slide eye bolts through receiver side holes and screw
into threaded holes in accessory base. Hand tighten all
eye bolts and then use screw driver shaft to tighten
one half turn.
