KIT CONTENTS
Unpack the installation kit and identify the required parts.
Item Part Number Description
Quantity
A
32-04040
Switch, Engage/Disengage, Momentary ..................................................................1
B
350-0024
Washer, Flat, 1/4” SST .............................................................................................2
C
350-0027
Washer, Flat, 5/16” SST ...........................................................................................3
D
350-0037
Washer, Narrow Flat, 3/8” SST ................................................................................2
E
350-0042
Washer, Split 5/16” SST ...........................................................................................2
F
350-0083
Nut, Whiz-Lock, 1/4” - 20 SST .................................................................................2
G
35-02183
Valve, FieldPilot, 1.1 GPM, OC ................................................................................1
H
35-02155
Assembly, Hydraulic Counter Balance .....................................................................1
I
45-07703
Harness, SCM .........................................................................................................1
J
45-10103
Harness, Valve .........................................................................................................1
K
60-01017
Washer, Flat, Fender 5/16” x 1-1/2” .........................................................................2
L
60-04089
Bolt, Hex 3/8”-16 x 3-3/4” SST .................................................................................2
M
60-04090
Bolt, Hex 1/4”-20 x 2” SST .......................................................................................2
N
60-04094
Bolt, Hex 5/16”-18 x 1-3/4” SST ...............................................................................1
O
60-04095
Bolt, Hex 3/8”-16 x 1-1/2” SST .................................................................................2
P
60-07027
Nut, NyLock 3/8”-16, SST ........................................................................................4
Q
65-05162
Bracket, Hydraulic Block Mount ...............................................................................1
R
65-05175
Bracket, CB Valve Mount - SC4XXX........................................................................1
S
68-01221
Hose, Hydraulic 3/8” x 66” #6femJICswiv x #6femJICswiv ......................................1
T
68-01098
Hose, Hydraulic 1/2” x 64” #8femJICswiv x #8femJICswiv90EL .............................1
U
68-01099
Hose, Hydraulic 1/2” x 70” #8femJICswiv x #8femJICswiv90EL .............................1
V
68-01100
Hose, Hydraulic 3/8” x 18” #6femJICswiv x #6femJICswiv ......................................2
W
68-01101
Hose, Hydraulic 3/8” x 10.0” #6femJICswiv x #6femJICswiv90EL ..........................2
X
68-01102
Hose, Hydraulic 3/8” x 22” #6femJICswiv x #6femJICswiv90EL .............................1
Y
68-01103
Hose, Hydraulic 3/8” x 11.5” #6femJICswiv x #6femJICswiv90 ...............................1
AA
68-02022
Adapter, Hydraulic Run Tee - #6 JIC........................................................................3
