2
FieldPilot ®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Flat, 3/8” SST .............................................................................................2
C 35-02180 Valve, FieldPilot 2.1GPM, CC, LS, PWM .................................................................1
D 45-05396 Cable, Power 3 POS AMP To 3-2 POS WP ............................................................1
E 45-07703 Harness, SCM .........................................................................................................1
F 45-10103 Harness, Valve .........................................................................................................1
G 60-04087 Bolt, Hex- 3/8-16 x 3-1/4” SST .................................................................................2
H 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................2
I 65-05177 Bracket, Hyd. Block Mount - JD7010 .......................................................................1
J 68-01031 Hose, Hyd. - 3/8” x 96”, #6FJIC x #8FORF ............................................................2
K 68-01111 Hose, Hyd. - 3/8” x 32”, #8FJIC x #8FJIC ...............................................................2
L 68-01220 Hose, Hyd. - 1/4” x 40”, #4FJIC Both Ends ............................................................1
M 68-02019 Adapter, Hyd. - #6MJIC x #6MORB .........................................................................2
N 68-02026 Adapter, Hyd. Run Tee - #8 ORF .............................................................................2
O 68-02063 Adapter, Hyd. 90º - #4MJIC x #6MORB ...................................................................1
P 68-02080 Adapter, Hyd. 90º - #6MJIC x #6MORB ...................................................................2
Q 68-02117 Adapter, Hyd. - #4MJIC x M12MORB ......................................................................1
R 68-02133 Adapter, Hyd. - #8MJIC x M22 x 1.5 M x 15mm tube ..............................................2
S 68-02146 O-Ring Metric 12mm ................................................................................................1
T 68-02150 O-Ring Metric 22mm ................................................................................................2
U 90-50013 Cable Tie Kit, 15 ......................................................................................................1
V 91-07011 Steering Wheel Switch Kit .......................................................................................1
W 98-05228 Installation Manual, John Deere 7x20 LF Series .....................................................1
