9
FieldPilot ®
1. PrePare the FieldPilOt ValVe
Install adapters (P) in the P & T ports. Install adapters (M) in the A & B ports.
Finally, install adapter (O) in the LS port.
Figure 1-4: Prepare the FieldPilot Valve
2. PrePare the POWer BeYONd BlOCK
Remove the three plugs from the P, T and LS ports of the Power Beyond Block.
Put o-ring (T) on adapters (R) and install adapters (R) in the P & T ports of the Power Beyond block.
Then put o-ring (S) on adapter (Q) and install adapter (Q) in the LS port.
Figure 1-5: Prepare The Power Beyond Block
o
M
M
p
p
r w/t
Q w/s
p port
t port
ls port
power Beyond Block
