FieldPilot ®
KIT CONTENTS
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Flat, 3/8″ SST .............................................................................................3
C* 35-02151 Valve, FieldPilot, CC LS ...........................................................................................1
C* 35-02180 Valve, FieldPilot, CC LS, PWM ................................................................................1
D 45-07703 Harness, SCM .........................................................................................................1
E 45-10103 Harness, Valve .........................................................................................................1
F 60-04087 Bolt, Hex- 3/8-16 x 3-1/4″ SST .................................................................................2
G 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................2
H 65-05162 Bracket, Hyd. Block Mnt ..........................................................................................1
I 68-01197 Hose, Hyd. - 1/4″ x 100″, #6FORF x #4FORF 90EL ................................................1
J 68-01198 Hose, Hyd. - 1/4″ x 120″, #6FORF x #4FORF 90EL ................................................1
K 68-01199 Hose, Hyd. - 3/8″ x 80″, #6FORF x #6FORF 90EL LONG .......................................1
L 68-01200 Hose, Hyd. - 3/8″ x 182″, #6FORF x #6FORF 90EL LONG .....................................1
M 68-01201 Hose, Hyd. - 1/4″ x 67″, #6FORF x #6FORF 90EL ..................................................1
N 68-02012 Hyd. Load Shuttle - #6FORB ...................................................................................1
O 68-02032 Adapter, Hyd. Run Tee - #4 ORF .............................................................................2
P 68-02071 Adapter, Hyd. Run Tee - #6 ORF .............................................................................2
Q 68-02072 Adapter, Hyd. 90 Elbow - #6maleORF x #6femORF ...............................................1
R 68-02073 Adapter, Hyd. - #6MORF x #6MORB .......................................................................3
S 68-02074 Adapter, Hyd. 90 EL - #6MORF x #6MORB ............................................................4
T 68-02110 Adapter, Hyd. - #6FORF x #6MORB .......................................................................1
U 90-50013 Cable Tie Kit, 15 ......................................................................................................1
V 91-07011 Steering Wheel Switch Kit .......................................................................................1
W 98-05161 Installation Manual FP, JD 4700 ..............................................................................1
* The valve included depends upon which vehicle kit was ordered.
