Page 20
www.teejet.com
19
FieldPilot
®
11. RECOMMENDED ELECTRONICS INSTALLATION
The Steering Control Module (SCM) should be securely mounted as level as possible to the floor. It must be
mounted with the arrows pointing toward the direction of travel. The control console can be mounted to the
preference of the operator. The GPS antenna should be mounted as far forward as possible on the cab on a
metal surface of at least 4″ square.
Figure 1-12: Recommended Electronics Installation
SCM
Console
GPS Antenna
