FieldPilot ®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Flat - 3/8” SST ...........................................................................................4
C 35-02184 Valve, FieldPilot PWM, 7.9GPM, OC .......................................................................1
D 45-07703 Harness, SCM .........................................................................................................1
E 45-10103 Harness, Valve .........................................................................................................1
F 60-04089 Bolt, Hex- 3/8-16 x 3-3/4” SST .................................................................................2
G 60-04088 Bolt Hex 3/8-16 X 1-1/4” SST ..................................................................................1
H 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................3
I 65-05162 Mounting Bracket .....................................................................................................1
J 68-01145 Hose, Hyd. - 5/8” x 57”, #12FJIC x #12FJIC 90º .....................................................1
K 68-01146 Hose, Hyd. - 5/8” x 52”, #12FJIC x #12FJIC 90º .....................................................1
L 68-01147 Hose, Hyd. - 3/8” x 52”, #8FJIC x #8FJIC 90º .........................................................1
M 68-01148 Hose, Hyd. - 1/2” x 51”, #8FJIC x #10FJIC 90º .......................................................2
N 68-02017 Adapter, Hyd. - #12MJIC x #12MORB .....................................................................2
O 68-02044 Adapter, Hyd. Run Tee - #10 JIC .............................................................................2
P 68-02051 Adapter, Hyd. 90º - #12MJIC x #12FJIC ..................................................................2
Q 68-02056 Adapter, Hyd. - #16FJIC x #8MJIC ..........................................................................1
R 68-02057 Adapter, Hyd. Run Tee - #16 JIC .............................................................................1
S 68-02093 Adapter, Hyd. 90º - #8MJIC x #8FJIC ......................................................................3
T 68-02094 Adapter, Hyd. - #8MJIC x #8MORB .........................................................................3
U 90-50013 Cable Tie Kit, 15 ......................................................................................................1
V 91-07011 Steering Wheel Switch Kit .......................................................................................1
W 90-02472 Kit, Patch Antenna Extention, 10’ .............................................................................1
X 91-00022 Kit, Articulated Gyro Module ....................................................................................1
Y 98-05127 Ford Versatile 856,876,936,946,976 FieldPilot Installation Manual .........................1
