6. install the shuttle tees
Install the two prepared shuttle tees on to the steering ports as shown.
On E-Series machines the shuttle tee with adapter
(R) must be attached to the port without adapter (T) .
Then reattach the original steer hoses to the center port of the appropriate shuttle tee. (E Series will look
slightly different than pictures.)
Figure 1-10: Install the Shuttle Tees
Attach original steer hoses here
