8
FieldPilot ®
iNstAllAtioN
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to
the changes in component specifications the parts supplied in the kit are not exactly as presented
in this document, please contact your dealer or TeeJet Customer service representative for
clarification before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of
the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY
DON’T INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Overview of the Machine
• The FieldPilot valve will mount on the right side of the machine just ahead of the cab.
• The hydraulic connections will all be made at the machine’s steering valve.
• The cables will enter the cab from the bottom-right-rear.
• The GPS antenna will mount on the cab as far forward as possible.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-2: Overview of the Machine
Gps
Fieldpilot
Valve
Cable
entrance
Hydraulic
Connections
