S YSTEM LH 500 S LURRY COMPUTER OPERATORS MANUAL
Input Description
Thresher RPM signal from the thresher speed sensor.
Grain
elevator RPM signal from the grain elevator speed sensor.
Return
elevator 1 RPM signal from the return elevator 1 speed sensor.
Press the ARROW DOWN key to see the next inputs:
Straw walker RPM signal from the straw walker speed sensor.
Feed auger
RPM signal from the feed auger speed sensor.
Reel RPM signal from the reel speed sensor.
Press the ARROW DOWN key to see the next inputs:
Feed auger
status Signal from the feed auger status sensor.
Chopper
status Signal from the chopper status sensor
Fan speed RPM signal from the fan speed sensor.
Press the ARROW DOWN key to see the next inputs:
Chopper RPM signal from the chopper speed sensor.
Sieve loss Signal from the sieve grain loss sensor.
Walker loss Signals from the straw walker grain loss sensors.
Press the ARROW DOWN key to see the next inputs:
Return
material Signal from the return materials sensor.
Forward
speed Signal from the forward speed sensor.
Auto/man
reel speed Signal from the auto/man reel speed sensor.
Press the ARROW DOWN key to see the next inputs:
Straw
compartmen
t Signal from the straw compartment sensor.
Return
elevator 2 RPM signal from the return elevator 2 speed sensor.
Header
height Current from the header height sensor.
Press the ARROW DOWN key to see the next inputs:
Grain tank
full Signal from the full grain tank sensor.
