Technical Specifications
Analog Inputs
Š 1/4” Phone Jack, Input Impedance: 1MOhm
Š Max Input Level 16 dBu @ 12V supply
Analog Outputs
Š 1/4” Phone Jack
Š Output Impedance 0 Ohm, Sense 225 Ohm
Š Max Output Level @ 16 dBu @ 12V supply
Š Dynamic Range, 106/98 dB, 20 Hz to 20 KHz @ Input
Level 16/-2 dBu, not A-weighted
Š THD < -90 dB (0.0032%) @ 1 kHz, I/O Level 16 dBu,
Load > 2400 Ohm
Š Frequency Response, +0.1/-0.2 dB, 20 Hz to 20 KHz
Conversion Characteristics
Š Sample Rate 48 kHz, Converter AKM AK4620B
Š AD / DA Conversion 24 bit, 128x oversampling
bitstream
MIDI:
Š In/Out – 5 pin DIN
EMC & Safety
Š Complies with EN 55103-1 and EN 55103-2 FCC part
15, Class B, CISPR 22, Class B
Š Certified to IEC 65, EN 60065, UL6500 and CSA E60065
CSA FILE #LR108093
Environment
Š Operating Temperature 32° F to 122° F (0° C to 50° C)
Š Storage Temperature -22° F to 167° F (-30° C to 70° C)
Š Humidity Max. 90 % non-condensing
Supplementary
Š Dimensions 130mm x 132mm x 41mm (5" x 5.25" x
1.5")
Š Weight 1.5 lb. (0.72 kg)
Š Warranty Parts and labor 1 year
