Using the OMEGAMON II for DB2 Callable Interface
98 OMEGAMON II for DB2 User’s Guide: CUA Interface, Version 540
Setting Up the D2/EXPLAIN Options
Use the following procedure to set up the D2/EXPLAIN options.
SAVE/EXPLAIN Use this option to perform SAVE and EXPLAIN functions. Complete the
required fields for the SAVE/EXPLAIN option.
Step Action
1 If you are not already logged onto CUA, then do so now.
2 From the main CUA panel (KD2001), select Options from the task bar and press
Enter. The following pop-up appears.
3 Select option 8, D2/Explain Options, from this panel and press Enter. Use the
D2/EXPLAIN Options panel, shown below, to specify parameters required to
invoke !DB/EXPLAIN during your OMEGAMON session.
Values for SQL
Process Level
Description
1. Preferences...
2. Controls...
3. Set thresholds...
4. User authorities...
5. User Profiles...
6. Subsystem Profiles...
7. Near-term Thread History Filter...
8. D2/Explain Options...
F1=Help F12=Cancel
D2/EXPLAIN Options
Extract Id . . . . . . : DB41
User Profile DSN . . . :
Group Profile DSN. . . :
SQL Statement PDS. . . :
Member Name. . . . . :
Type of Save . . . . : REPLACE +
Default Qualifier. . . : SYSIBM
Qualifier Option . . : PROMPT +
Gather Statistics. . . : YES +
Initial Report . . . . : EPATH+
F1=Help F4=Prompt F12=Cancel
