Sure Heat 2007 Amana SF27 - Manual (Page 7)

7
Grill Out of Box
12a
7d
4a
5a
8d
3d
6a
6d
4b
12b
1a
12c
2a
2c
2e
Open Box Carefully – Lay Out All Parts
2a. Cart Side Left
12b. Main Cooking Grate
2c. Cart Side Right
6a. Cart Door Left
6b Cart Door Right
2e. Cart Back
1a. Cart Base
12c. Bread Warmer Grate
3d. Spare LP Gas Tank Barrier
5a. Grill Head Assembly
4b. Drip Pan
8d. Side Burner Shelf Assembly
12a. Flavor Grid
7d. Side Shelf Left Assembly
1b Caster Assembly Left (Swivel wheels)
1c Caster Assembly Right (Swivel Wheels with lock)
Not Shown:
Small Components Package
Tank Secure Ring
1c
1b
