Sure Heat 2007 Amana SF27 - Manual (Page 16)

STEP NINE
a. Place the electronic igniter into the igniter hole on
the front left of the side burner shelf. To help ease
the installation of the wires, make certain that the
igniter wire tabs are facing away from the grill.
b. Secure the igniter in place using the plastic lock nut.
Make sure to tighten securely.
c. Install AA battery, negative side first.
d. Install spring and cap assembly and tighten
securely.
e. Attach loose wire to bottom of side burner, and then
to any of the open tabs in the igniter. Insert the
other igniter wire from the side of grill into the
remaining hole.
Note: The igniter is designed in such a way
that it does not matter which terminal tab is
used when connecting igniter wires.
Grill Assembly
16
9a
9b
9c
9d
Close-up of igniter wires attaching to igniter.
Close-up of igniter wire attaching to burner.
9e
