Sure Heat 2007 Amana SF27 - Manual (Page 17)

STEP TEN
a. Remove two screws from the side burner valve
assembly.
b. Carefully insert the valve assembly into the cast
burner. You will need to angle the tube into the
burner assembly. Make certain that the hose is
pointing down when the valve is put in place.
Then push the valve stem out through the open-
ing in the front of the side burner shelf assembly,
lining up the holes on the valve assembly with the
openings on the burner shelf.
c. Place bezel into place, with the "off" position
pointing up, making sure to line up holes.
d. Attach bezel to assembly face with screws removed
in step 11a.
e. Press knob onto valve assembly stem.
Grill Assembly
17
10d
10c
10b
10e
close-up of step 10b
