Instruction Manual

5

Installing the Remote Unit

1. Place the Remote Unit near the computer.
2. Switch off the computer and disconnect any existing VGA and input connections.
3. Using a StarTech.com integrated KVM cable (see page 15 for part numbers), connect the end

of the cable that has two (USB) or three (PS/2) connectors to the VGA Out connector and the

USB or mouse and keyboard PS/2 connectors on the computer as appropriate. (The PS/2

version of the cable is color-coded.) Connect the opposite end of the cable with a single

connector to the gray-coded connector marked COMPUTER on the Remote Unit of the KVM

extender.

4. Connect a USB mouse, keyboard, and a VGA monitor to the indicators marked as CONSOLE

on the Remote Unit.

5. Connect the UTP cable connection for Remote Unit to the NETWORK RJ-45 connector on

the Remote Unit. Connect the opposite end to a terminated wall outlet (if using premises

cabling).

CAUTION: The UTP network cables that connect the Host and Remote Units

carry electrical current and should not be plugged in to other devices, as they

may cause damage. We strongly recommend marking the cables you are

using with this product at both locations for easy identification.
