Specifications
PART NUMBERING KEY
Model
EXAMPLE:
Option
ASC-Plus - A
MODEL OPTIONS
ASC-Plus A - Temperature Compensation
Specifications and product availability subject to change without notice.
PARAMETERS UNITS VALUE
Nominal Voltage (Volts) 12
Short Circuit Current, Continuous (Amps) 15
Short Circuit Current, Max (60 seconds) (Amps) 18
Load Current, Continuous (2) (Amps) 10
Load Current, Max (60 seconds) (2)(4) (Amps) 13
Array Voltage, Max Voc (Volts) 26
Voltage @ Battery for Charging, Minimum (Volts) 0
Voltage @ Battery for LVD, Minimum (Volts) 8.5
Quiescent Current (Milliamps) 15
Current Consumption, Charging, Typ. (Milliamps) 20
Current Consumption,
Load Disconnected, Typ. (3) (Milliamps) 40
Voltage Drop, Array to Battery, Typ. (Volts) .40
Voltage Drop, Battery to Load, Typ. (Volts) @ 10 amps .06
Charge Termination (Volts) 14.3 + .2
Charge Resumption (Volts) 13.5 + .3
Load Disconnect (LVD) (Volts) 11.5 + .2
Load Reconnect (Volts) 13.0 + .3
Operating Temp. Range (
°
C) 0 to 50
Storage Temp. Range (
°
C) -55 to 85
Temperature Comp. Coef. (from 25
°
C) (1) (Volts/
°
C) -.03
Notes: (1) Temperature compensation option
(2) Non-inductive.
(3) LVD relay energized, red L.E.D. on, typical value.
(4) Carry only, Non-switching
