ASC-Plus PROBLEM CHART :
- Refer to this chart and the ASC-Plus
PROBLEM DESCRIPTIONS (next page), to help diagnose potential problems based
on the observations of the ASC-Plus and actual battery voltage. The use of a voltage
multi-meter may be helpful.
Problems with charging
CASE BATTERY VOLTAGE
(use multi-meter at
battery terminals)
CHARGE
LIGHT “LOAD
DISCONNECTED”
LIGHT OTHER ASC-Plus
CASE NOTES
(next page)
1
→
Low voltage
(9.0 - 13.2 volts)
ON Day time See Case 1
(next page)
2
→
Low voltage
(9.0 - 13.2 volts)
OFF Day time See Case 2
3
→
Moderate voltage
(13.2 - 14.0 volts)
Turns OFF
(too soon)
Day time See Case 3
4
→ High voltage
(14.4 - 15.0 volts)
ON See Case 4
5
→
High voltage
(14.4 - 15.0 volts)
OFF See Case 5
6
→
ON - at night See Case 6
7
→
Light going on
and off rapidly See Case 7
8
→
ASC-
Plus
buzzing See Case 8
9
→
ASC-
Plus hot See Case 9
Problems with low-voltage load disconnect
CASE BATTERY VOLTAGE
(use multi-meter at
battery terminals)
CHARGE
LIGHT “LOAD
DISCONNECTED”
LIGHT OTHER ASC-Plus
CASE NOTES
(next page)
10
→
Very low voltage
(11.5 volts or lower)
OFF Loads
stay on See Case 10
11
→
Low to Moderate voltage
(11.5 - 14.3 volts)
ON Loads off See Case 11
