1.2 How to connect CS-CAN with a CAN device
CS-CAN
CAN
Device
VCC(DC +5V)
CAN_H(CAN_High)
CAN_L(CAN_Low)
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
GND
※ CS-CAN receives its power from CAN BUS. In order to supply the power, VCC and GND
must be connected.
