4.
Features in CS-CAN utility
3.3. Port window
Port window is shown as below. Light grey background indicates, it is in Read Only
attribute.
White background indicates that the value can be modified. Dark grey indicates that
CS-CAN cannot be detected from the COM port.
The descriptions for the buttons on the top part of Port window are as follows.
Buttons Description
Read Status Read details from CS-CAN
Config Modify settings in CS-CAN
F/W Upgrade Upgrade firmware in CS-CAN
Clear
Reset the numbers in Tx , Rx , Error Count and the contents in
the Terminal
Send Frame Transmit CAN frame
Terminal Terminal window is created for incoming data.
Random Generates random data when Send Frame is clicked.
