16
Features in CS-CAN utility
Descriptions for each fields are as follows.
Type Control Description
RS232
Baud rate
Set Baud rate in CS-CAN
(1200, 2400, 3600, 4800, 9600, 14400, 19200, 38400,
57600, 115200) bps
Data bits
Set Data bits in CS-CAN
(Commands are in ASCII format, therefore only 8bits are
supported)
Stop bits Set Stop bits in CS-CAN (1bit, 2bits)
Parity bits
Set Parity bits in CS-CAN
(None, Odd, Even, Mark, Space)
CAN
Baud rate
Set Baud rate in CS-CAN
(83000,.100000, 125000, 250000, 500000, 1000000) bps
Spec. Set CAN Spec. in CS-CAN (Spec A and B)
ID
Set Message ID that you wish to receive.
(Spec A : 0x000~0x7FF
Spec B : 0x00000000~0x1FFFFFFF)
Mask
Mask message ID that you wish to receive.
(Spec A : 0x000~0x7FF
Spec B : 0x00000000~0x1FFFFFFF)
