Eddy-ZB User Guide
J7
Pin No Name Description
1 R0_7 Port 0.7 Digital I/O
2 R0_6 Port 0.6 Digital I/O
3 DTR#1 UART1 Data Terminal Ready
4 DSR#1 UART1 Data Set Ready
5 -6 3V3 3V –3.6V power-supply connection
7 BHDM USB differential data minus
8 BHDP USB differential data plus
9 RXD#2 UART2 Receive Data
10 TXD#2 UART2 Transmit Data
11 NRST Reset(active-low)
12 - 13 GND Ground
14 - 16 WPID[0:2]
Product ID only used by the manufacturer.
Please do not work on these pins.
17-18 NC Not Connected
