Pinout for j1, j5, and j7, Eddy-zb user guide – Solvline Eddy- ZB v1.0 User Manual
Page 6
Eddy-ZB User Guide
B. Pinout for J1, J5, and J7
J1
J5
J7
Pin Description
Pin
Description
Pin
Description
1
NC
1
GND
1
P0_7
2
NC
2
3V3
2
P0_6
3
NC
3
DBC
3
DTR#1
4
3V3
4
DBD
4
DSR#1
5
P0_0
5
NC
5
3V3
6
RXD#1
6
NC
6
3V3
7
TXD#1
7
NRST
7
BHDM
8
CTS#1
8
NC
8
BHDP
9
RTS#1
9
NC
9
RXD#2
10
P0_1
10
TXD#2
11
NC
11
NRST
12
NC
12
GND
13
NC
13
GND
14
NC
14
WPID0
15
NC
15
WPID1
16
NC
16
WPID2
17
NC
18
NC
