Eddy-ZB User Guide
7. LED
All
devices
except the coordinator will search for target devices using destination ID. When the connection is
made, the link LED will be on and stay on. When the data is transmitted but there is no reply from the
target device, it will assume that the link is break and turn off the link LED. Therefore, unless the data
transmission event is generated, even if the status of the target device is changed, the link LED will
remain its status until the data transmission event affects and updates the link LED status.
LED Status Meaning
RDY
(Green)
Blink Normal Operation
Off System Error
Link
(Red)
ON
Network Connection Complete (For a
coordinator, automatically on)
Blink
Search for target devices and attempts network
connection
Off Connection Fail
