Technical Data
EM-10 Electric Boiler Temperature Control
Packaged weight — 0.38 lb. (170 g)
— Enclosure D, black noryl plastic
Dimensions — 4-3/4” H x 2-7/8” W x 1-7/8” D (120 x 74 x 48 mm)
Approvals — ANSI Z21.23, CAN 1-6.6-M78-R2001, UL873, UL840
Ambient conditions — Indoor use only, -40 to 140°F (-40 to 60°C),
< 90% RH non-condensing
Power supply — 24 V (ac) ±10% 50/60 Hz 75 VA
Pump / Stage 1 Relays — 120 V (ac) 5 A 1/6 hp pilot duty 240 VA
Stage 2, 3, 4 Relays — 120 V (ac) 3 A 1/6 hp pilot duty 240 VA
Demands — 24 to 120 V (ac) 2 VA
Sensors — NTC thermistor, 10 kø @ 77°F (25°C ±0.2°C) ß=3892
included: — 1 of Universal Sensor 071 with 96" long wires (S/F P/N 790400000)
Outdoor Sensor 070 (S/F P/N 339070000)
optional: — Universal Sensor 071
Publication No. EM-10-40 Printed in U.S.A. 809 Part No. 792820000
