13 EM-10-40 Operation and Instruction Manual
Mode 4 and 5 – Outdoor Reset and Setpoint Operation - View Menu
s s e c c A n o i t p i r c s e D e g n a R d l e i F m e t I
-60 to 190°F
(-51 to 88°C)
OUTDOOR
Current outdoor air temperature as measured by the
outdoor sensor.
Factory
Installer
- - - ,
35 to 266°F
(2 to 130°C),
OFF
BOILER TARGET
The boiler target is the temperature the control is
currently trying to maintain at the boiler supply sensor
or the boiler outlet sensor.
Factory
Installer
14 to 266°F
(-10 to 130°C)
BOILER SUPPLY
Current boiler supply water temperature as measured
by the boiler supply sensor.
Note: This item is only available when MODE is set to 5.
Factory
Installer
14 to 266°F
(-10 to 130°C)
BOILER OUTLET
Current boiler outlet water temperature as measured
by the boiler outlet sensor.
Note: When MODE is set to 5 this item is only visible
in the Factory access level.
Factory
(Installer for
Mode 4)
14 to 266°F
(-10 to 130°C)
BOILER INLET
Current boiler inlet water temperature as measured by
the boiler inlet sensor.
Note: This item is only available when a boiler inlet
sensor is installed.
Factory
Installer
0 to 252°F
(0 to 140°C)
BOILER DELTA T
Current temperature difference between the boiler outlet
sensor and the boiler inlet sensor.
Note: This item is only available when a boiler inlet
sensor is installed.
Factory
0 to 999
BOILER ON HOURS
The total number of running hours of the boiler since
this item was last cleared. Clear the numbers of hours
while viewing this item.
Factory
V
IE
W
M
E
N
U
After the last item, the control returns to the first item in the menu.
The View menu items display current operating
temperatures and system status information.
Use the
Item button to view items in this menu.
Item
View Next Item
