Slant/Fin EC-10 Assembly Instructions - Manual (Page 4)

4
3
4
3
5
4
4.2
4.3
8575N018
8575N019
Loosen the 2 top and bottom nuts.
Remove the lower and upper hinges.
8575N020
13
1
2
1
2
- Remove the cast iron hinge pin for the burner door
fixed by the 2 screws . Put the two screws back
on the right-hand side
- Reinstall the cast iron hinge pin for the burner door
on the left side using the 2 screws .
Reverse the direction of opening of the burner door if necessary
(opening at left).
2
6
2
6
- Reinstall the hinge pins on the left side, fixing them
using the nuts located on the burner door hinge pins, on
the left side, as shown on the adjacent figure.
- Tighten the 2 nuts .
4.1
When the burner leaves the factory, the burner
door opens towards the right. Perform operations
4.1, 4.2 and 4.3 below to open the burner door
towards the left (if absolutely necessary).
