9.2. Extractor
1. Fit extractor to bolt body by holding bolt in one hand; and
2. While applying pressure with thumb over the spring end of the extractor, slide extractor pin into hole until ends are
flush with bolt body.
FIG 43 EXTRACTOR TO BOLT BODY
